Cisco UCS C220 M5 1U Rack Server

Description: Cisco UCS C220 M5 1U Rack Server with 1 x Intel Xeon Bronze 3204 / 6 Core processor |1 x 16GB RAM |1 x 600GB 10K RPM HDD | RAID Controller | Inbuilt Power Supply with 3 Years Manufacturer Warranty.

Processor

Dual Intel Xeon Scalable CPUs with up to 28 cores per socket

Memory

24 DDR4 DIMM slots: 8, 16, 32, 64, and 128 GB up to 2666 MHz

Support for the Intel Optane DC Persistent Memory (128G, 256G, 512G)

PCIe Slots

2 PCIe 3.0 slots plus 1 dedicated 12-Gbps RAID controller slot and 1 dedicated mLOM slot

Hard Drives

●  Up to 10 x 2.5-inch SAS and SATA HDDs and SSDs and up to 2 NVMe PCIe drives

●  Up to 10 x 2.5-inch NVMe PCIe drives

●  Up to 4 x 3.5-inch SAS and SATA HDDs and SSDs and up to 2 NVMe PCIe drives

Embedded Network Interface Cards (NICs)

Dual 10GBASE-T Intel x550 Ethernet ports

RAID controllers

●  Internal controllers: Cisco 12-Gbps Modular RAID Controller (PCIe 3.0) with 1- or     2-GB Flash-Backed Write Cache (FBWC), providing enterprise-class data protection for up to 10 SAS and SATA Hard-Disk Drives (HDDs), SSDs, or NVMe PCIe SSDs; or Cisco 12-Gbps Modular SAS Host Bus Adapter (HBA)

●  External controller: Cisco 12-Gbps 9400-8e SAS HBA

Power supplies

Hot-pluggable, redundant 770W AC, 1050W AC, 1050W DC, and 1600W AC

Cisco UCS C220 M5 1U Rack Server with 1 x Intel Xeon Bronze 3204 / 6 Core processor |1 x 16GB RAM |1 x 600GB 10K RPM HDD | RAID Controller | Inbuilt Power Supply with 3 Years Manufacturer Warranty.
